48
GB
Figure 1
Model
12P CA-E 16P CA-E 20P CA-E 12HP CA-E 16HP CA-E 20HP CA-E
A ø - mm 495 495 495 495 495 495
B mm 230 230 230 230 230 230
C mm 310 310 310 310 310 310
D mm 56 56 56 56 56 56
E ø - mm 80 80 100 100 100 100
F mm 1200 1450 1700 1200 1450 1700
G mm 1115 1365 1615 1115 1365 1615
H mm 175 min 175 min 175 min 175 min 175 min 175 min
M mm 520 min. 520 min. 520 min. 520 min. 520 min. 520 min.
N mm 250 min. 250 min. 250 min. 250 min. 250 min. 250 min.
b1 Water inlet
b2 Water outlet
c Drain / recirculation
d Gas supply
e Flue gas exhaust
Carry out the installation as to standards.
STANDARDS FOR INSTALLATION
Place the wall mounted heater near an out-
side wall or a chimney (fi gure 8) on which
the fl ue gas exhaust / outside air intake de-
vice can be installed.
When selecting the position of the terminal
on an outside wall, follow the applicable lo-
cal and national regulations.
If the water heater is to be installed in a
corner between two walls, leave, between
the wall and the heater, enough space for
installation and removal of the components.
POSITIONING
