Ariston 100 L Technical Manual

17
Anti-noise filter
It filters possible electric disturbs coming from the mains.
Box Plastics, component sealed with resin auto extinguisher
Terminals 5 Faston 6,3x0,8mm
Tension 125/250Vac
Current 16A (40°C)
temperatures interval of operation -25°C/+100°C
Dispersion current 2.3mA
Condenser (Component not supplied as spare part)
The condenser is wrapped around the tank
It receives high pressure and temperature vapor from the compressor.
Inside it the refrigerant liquid changes its physical state. It passes from vapor to liquid losing heat (given to
the water) during the state passage, the quantity of heat it is equal to the sum of the absorbed heat in the
evaporator and of the heat energy of the compression.
Mainboard

Ariston 100 L Specifications

General

Power Source	Electric
Pressure Rating	8 bar
Capacity	100 L
Type	Storage Water Heater
Thermostat	Adjustable
Temperature Range	Up to 75°C
Insulation	Polyurethane Foam
Warranty	2 years
Dimensions	Varies by model (approx. 913mm x 450mm x 480mm)
Weight	Varies by model (approx. 27 kg)
