Ariston 100 L Technical Manual

22
BOOST mode
This mode is available by default.
The BOOST is a temporary mode that shall be set by the user when he has an urgent need of hot
water.
By activating this mode, the water heater simultaneously uses the heat pump and heating element
to reach the desired temperature in the shortest possible time. Once this temperature is reached,
the operating mode will automatically go to AUTO mode (with previous settings).
Useful parameters:
Parameter Description/Functioning Range
Default
value
T
set-point
The desired temperature for the hot water can be set by turning the knob clockwise or
anti-clockwise.
T
min
÷ T
max
55 °C
T
max
Installer menu parameter P1 - Adjustment of the maximum obtainable temperature. 65 °C ÷ 75 °C 65 °C
T
min
Installer menu parameter P2 - Adjustment of the minimum obtainable temperature. 40 °C ÷ 50 °C 50 °C
T
HP
Installer menu parameter P3 - Adjustment of the maximum temperature obtainable
with the heat pump unit.
50 °C ÷ 62 °C 55 °C
T
water
The temperature of the water in the tank, to visualize press and release the knob; the
relative value will appear for 8 seconds then the set temperature will reappear.
- -
Legend:
HP: Heat pump
HE: Electrical resistance (1200 W)
Case 1: T
set-point
≤ T
HP
