Ariston 100 L Technical Manual

36
Component
Fault cause



Fault mode
What to check
What to do
Boiling
water or
steam
from taps
heating element
zone and hot
water sensors
faulty component → out of tune
Verify with a tester that the resistance
between terminals is compliant with
the “SENSOR TEST TABLE”
If the component is faulty, replace it
incorrect positioning Verify the proper positioning
Place the component in the right
position
-
High level of scaling of the boiler and
components
Drain the tank and check the
component
Provide water with proper hardness
degree
mainboard faulty component → malfunctioning
Check if the water heating doesn
’t stop
even if the set point temperature is
reached
If the component is faulty, replace it
Component
Fault cause



Fault mode
What to check
What to do
Noise
increases
from the
external
unit
Components vibration
Check the components fixed with
screws
Be sure that the screws are tight
fan
physical impediments to the movement of
fan blades → malfunction
Visual check of the component Clean the component
evaporator due to ice, leafs, dirt → partially clogged Visual check of the component Clean the component
Component
Fault cause



Fault mode
What to check
What to do
Frequent
electrical
resistance
functioning
“Time W” value too low Check P9 parameter on Installer menu
Increase the availability of heating
time
Air temperature out of range
Verify the compliance of the
environmental conditions
Are not yet past 8 days
from
:
• First Time installation
• change of the parameter Time-W
• No power from mains
• P7 parameter set to OFF and outside
air temperature below 10 ° C
Wait 8 days and recheck
heating element
zone, air,
evaporator and
hot water sensors
faulty component → out of tune
Verify with a tester that the resistance
between terminals is compliant with
the “SENSOR TEST TABLE”
If the component is faulty, replace it
incorrect positioning Verify the proper positioning
Place the component in the right
position
fan
physical impediments to the movement of
fan blades → malfunction
Visual check of the component Clean the component
evaporator
due to ice, leafs, dirt
→
partially
clogged
Visual check of the
component
Clean the component
Component
Fault cause



Fault mode
What to check
What to do
Bad odor
Absence of a siphon or siphon empty
Check the presence of the siphon and
the level of water inside
Provide a siphon with the right level
of water
Component
Fault cause



Fault mode
What to check
What to do
Bad water
quality
outlet water pipe dielectric connection missing → corrosion Verify the presence of the connection
Clean the pipe and provide a
dielectric connection
For other problems please contact local technical assistance.

Ariston 100 L Specifications

General

Power Source	Electric
Pressure Rating	8 bar
Capacity	100 L
Type	Storage Water Heater
Thermostat	Adjustable
Temperature Range	Up to 75°C
Insulation	Polyurethane Foam
Warranty	2 years
Dimensions	Varies by model (approx. 913mm x 450mm x 480mm)
Weight	Varies by model (approx. 27 kg)
