Ariston 100 L Technical Manual

8
100 LITRES Mode: GREEN
Tair [°C] tH-Heating-up time [h:mm:ss] EH-Heating-up energy [kWh] COPt Qpr
-5 6.10.22 2,34 1,8 0,504
1 4.45.40 1,90 2,2 0,504
7 3.26.52 1,53 2,9 0,504
20 2.48.52 1,33 3,6 0,504
30 2.07.37 1,09 4,1 0,504
42 1.55.49 1,03 4,1 0,504
Max. amount of hot water in a single intake
V40 with water at 55°C 130 l (ratio 1,3)
V40 with water at 62°C 152 l (ratio 1,52)

Ariston 100 L Specifications

General

Power Source	Electric
Pressure Rating	8 bar
Capacity	100 L
Type	Storage Water Heater
Thermostat	Adjustable
Temperature Range	Up to 75°C
Insulation	Polyurethane Foam
Warranty	2 years
Dimensions	Varies by model (approx. 913mm x 450mm x 480mm)
Weight	Varies by model (approx. 27 kg)
