Schema installazione - Installation scheme - Esquema de instalación - Esquema da instalaçao
Corretto posizionamento apparecchio - Correct water heater positioning - Colocación correcta del aparato -
Correto posicionamento do aparelho
MOD. A B C D E F L M X Y Z
Ø 353
30 Multis 588 145 141 242 96,5 64,5 - - 353 373 -
50 Multis 588 145 141 491 96,5 64,5 - - 353 373 -
Ø 450
50V 553 163 - - 165 - - - 450 470 -
80V 758 163 - - 165 - - - 450 470 -
100V 913 166 - - 165 - - - 450 470 -
80 Multis 758 163 174 335 165 113 - - 450 470 -
100 Multis 913 166 177 487 165 113 - - 450 470 -
120 Multis 1108 166 177 682 165 113 - - 450 470 -
