Ariston GL 4 S User Manual

10
DESCRIPTION REF.
PART CODE DESCRIPTION REF.
1
100XL
V
ALVE (T&P 3/4”) ABC
2
570241
ANODE (MA
GNESIUM)
C
2 574305 ANODE (MAGNESIUM) AB
3
994147 GASKET WITH 4 BOLTS ABC
4
994140
LOCK
NUT
M6
ABC
5 HEATING ELEMENT (1500/120) AB
5
HEA
TING
ELEMENT (1500/120) C
6 WIRED THERMOSTAT AB
6
WIRED THERMOSTAT C
7 570341 HEATER WALL HANGING BRACKET C
8 PLASTIC COVER
9 KNOB
10
LAMP COVER
GL 2.5 S
GL4S, GL4CAS
GL 6+ S
A
B
C
ARISTON INTERIOR
COMPONENTS DIAGRAM
GL 2.5 S, 4 S, 4 CA S, 6+ S
mini-tank electric water heaters
