Ariston LI 680 PLUS - Description of the Appliance; Overall View; Control Panel

16
EN
Overall view
1. Upper rack
2. Upper sprayer arm
3. Tip-up compartments
4. Rack height adjuster
5. Lower rack
6. Lower sprayer arm
7. Cutlery basket
8. Washing filter
9. Salt dispenser
10. Detergent and rinse aid dispensers
11. Data plate
* Only available in selected models.
3
1
Control panel
Description of the appliance
4
6
9
11
2
7
8
10
5
WASH CYCLE SELECT
button
EXTRA DRYING
button*
HALF LOAD
button*
DELAYED START
button*
HALF LOAD ON
UPPER RACK
indicator light*
DELAYED
START
indicator light*
2h
4h
6h
1
2
ON/OFF
button
ON/OFF
indicator light
HALF LOAD ON
LOWER RACK
indicator light*
LOW SALT
indicator light*
LOW RINSE AID
indicator light*
WASH CYCLE
indicator lights
