18 /

INSTALLATION

Electrical diagram

Fan

Wentylator

230VAC(50Hz)

Igniter

Flame Detect

Gas Valve

Zawór gazu

Gas proportional valve

Gas Separate

Valve_1

Gas Separate

Valve_2

Gas Separate

Valve_33

Water Inlet Temperature Sensor

Water Outlet Temperature Sensor

Water Flux Sensor

Overheat thermostat

ECO
