Aritech ATS1192 Installation Sheet

2 / 22 P/N MAINST-ATS1190 • REV E • ISS 14DEC20
accessing its on-line Menu system when connected to the
RS485 BUS can change this. See the Programming Guide,
Reader Address, for further details.
Tamper
The reader is provided with a Tamper facility. When connected
to the BUS, Tamper data is transmitted to the Advisor Master
with system data. An external Open Collector output (violet
wire) can be configured as a Tamper control for both online
and offline operation.
Reader wiring
WARNING! Wire insulation of cables connected to
the equipment must conform to IEC 60332-1-2 and
IEC 60332-1-3 or IEC 60332-2-2, depending on the
wire cross sectional area, or IEC TS 60695-11-21,
regardless of cross sectional area. Alternatively, such
wires must comply with UL 2556 VW-1.
Red
Positive 9 to 14 VDC supply
Black
0 Volts
DC supply ground
Green
D0/D− Clock
RS485 Data − Wiegand Data 0
Absolute maximum, 12 V @ 10 mA
White
D1/D+ Data
RS485 Data + Wiegand Data 1
Absolute maximum, 12 V @ 10 mA
Brown
LED 1
Offline LED control configured to “Two Wire
Control” will control the red LED only
Wire grounded: Red LED on
Wire open: Red LED off
Wire at +5 V to +12 V: Red LED off or, offline
LED control configured to “One Wire Control”
will control both the red and blue LED’s
Wire grounded: Blue LED on
Wire open circuit: Both LED’s off
Wire at + 5 V to 12 V: Red LED on
Absolute maximum, 14 V
Yellow
LED 2
Configurable to control the blue LED when
offline
Wire grounded: Blue LED on
Wire open: Blue LED off
Wire at +5 V to +12 V: Blue LED off
Request to exit input when online to Advisor
Master
This input may be connected to a simple push
button connected to Ground with RTE Only
selected on the option card or in Menu 10
(See Programming Guide for more details).
Blue
Buzzer
Offline Buzzer control.
Wire open or +5 V to +12 V: Buzzer off
Wire grounded: Buzzer sounding
Absolute maximum, 14 V
Violet
Open
Collector
Configurable as: Door relay, −Tamper output,
Credit controlled Pulsed, Timed or Latched
output
Note: This is a low current output and must
not be used to directly energise high current
door openers.
Absolute maximum, 14 V @ 25 mA
Specifications
Number of card combinations
28x10
12
— 48 bit
Supply voltage
9 to 14 V
Current consumption
25 mA
80 mA max.
Wireless operating frequency
119.0 to 128.6 kHz
Maximum power output
65.70 dBµA/m at 10 m
Dimensions of housing
ATS1190: 36 x 110 x 20 mm
ATS1192: 42 x 150 x 16 mm
Operating temperature
−35 to +66°C
Relative humidity
93%, noncondencing
Protection class
IP54
Regulatory information
Manufacturer
PLACED ON THE MARKET BY:
Carrier Fire & Security Americas Corporation Inc.
13995 Pasteur Blvd
Palm Beach Gardens, FL 33418, USA
AUTHORIZED EU REPRESENTATIVE:
Carrier Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Product warnings
and disclaimers
THESE PRODUCTS ARE INTENDED FOR SALE
TO AND INSTALLATION BY QUALIFIED
PROFESSIONALS. CARRIER FIRE &
SECURITY CANNOT PROVIDE ANY
ASSURANCE THAT ANY PERSON OR ENTITY
BUYING ITS PRODUCTS, INCLUDING ANY
“AUTHORIZED DEALER” OR “AUTHORIZED
RESELLER”, IS PROPERLY TRAINED OR
EXPERIENCED TO CORRECTLY INSTALL FIRE
AND SECURITY RELATED PRODUCTS.
For more information on warranty disclaimers and
product safety information, please check
https://firesecurityproducts.com/policy/product-
warning/ or scan the QR code.
Certification
EN 50131
EN 50131-1 System requirements
EN 50131-3 Control and indicating equipment
Security Grade 3, Environmental class II
Tested and certified by Telefication B.V.
Carrier Fire & Security hereby declares that this
device is in compliance with the applicable
requirements and provisions of all applicable rules
and regulations, including but not limited to the
Directive 2014/53/EU. For more information see:
firesecurityproducts.com
