Aritech DB2000 Series User Manual

2 / 16 P/N 10-4227-501-DB20-05 • ISS 05DEC16
DB2002 and DB2004 bases for 2000 Series detectors
Terminal connections are as follows:
• Terminal 1 – Remote indicator (positive)
• Terminal 2 – Remote indicator (negative)
• Terminal 5 – Line in / out (positive)
• Terminal 6 – Line in / out (negative)
DB2003 base for IU2016 Loop Isolator
Terminal connections are as follows:
• Terminal 1 – Line in (positive)
• Terminal 2 – Line out (positive)
• Terminal 3 – Line in / out (negative)
DB2016 Isolating Base for 2000 Series detectors
Terminal connections are as follows:
• Terminal 1 – Remote indicator (positive)
• Terminal 2 – Remote indicator (negative)
• Terminal 5 – Line in / out (positive)
• Terminal 6 – Not used
• Terminal 7 – Line in (negative)
• Terminal 8 – Line out (negative)
Maintenance
Basic maintenance consists of a yearly inspection. Do not
modify internal wiring or circuitry.
Testing the isolator
To test the isolator, provoke a short circuit in the loop and
check that the corresponding LED is activated.
Specifications
DB2002, DB2003, and DB2004
Number of terminals:
DB2002, DB2004
DB2003
4
3
Earth contact
Yes
Remote indicator option
Yes (DB2002, DB2004 only)
IP Rating
IP30
Operating temperature
Storage temperature
Relative humidity
−10 to +50ºC
−10 to +70ºC
10 to 95% noncondensing
Colour
White
D
imensions
DB2002, DB2003
DB2004
Ø 100 × 9 mm
Ø 100 × 17 mm
Weight:
DB2002, DB2003
DB2004
38 g
41 g
DB2016
Operating voltage
17 to 34 VDC
(28 VDC nominal)
Current consumption:
Standby
Isolated
Passing
< 30 µA
< 1.6 mA
Max. 800 mA
Line resistance
0.1Ω
Number of terminals
5
Earth contact
Yes
Remote indicator option
Yes
IP rating
IP30
Operating temperature
Storage temperature
Relative humidity
−10 to +50ºC
−10 to +70ºC
10 to 95% noncondensing
Colour
White
Dimensions
Ø 100 × 13 mm
Weight
49 g
Regulatory information
This section provides a summary on the declared performance
according to the Construction Products Regulation (EU)
305/2011 and Delegated Regulations (EU) 157/2014 and (EU)
574/2014.
For detailed information, see the product Declaration of
Performance (available at www.utcfssecurityproducts.eu
).
EU compliance
Certification body
0786
Manufacturer
Thunderous Sounders Electronics Co. Ltd.,
No, 21, Kai Fe 3rd, Pao En Industrial Area,
Ren De Village, Tainan, Taiwan, R.O.C.
Authorized EU manufacturing representative:
UTC Fire & Security B.V., Kelvinstraat 7, 6003
DH Weert, Netherlands
Year of first CE
marking
09
Declaration of
performance number
360-4227-0699
Product identification
DB2016
Intended use
See the product Declaration of Performance
Declared
performance
See the product Declaration of Performance
EN 54
EN 54-17:2005 + AC:2007
Contact information
For contact information, visit www.utcfssecurityproducts.eu.
