3. To retract, squeeze handle and push the section inward until fully aligned with mattress rail.
For right patient side: To retract sections, rst need to be retracted R1 and then section R2. Sections R3/
R4 move independently.
For left patient side: To retract sections, rst need to be retracted L1 section rst and then section L2.
Sections L3/L4 move independently.
4. Repeat this step for all eight extension handles.
Deck height
These buttons raise and lower the deck. All sections will lower at maximum speed until the bed
reaches low height (47cm*) where the movement will stop. When the lowering button is pushed
again, it will start to lower at a quarter speed until it has reached extra low height (38cm*). The
deck will not lower to extra low height if the bed platform is tilted (in Trendelenburg or reversed
Trendelenburg position).
(*Low height and extra low height dimensions are for reference only.)
CAUTION
To prevent damage to the bed as well as an unsafe condition, make sure that all four width
extensions on one side or all width extensions on both sides are in the same position.
WARNING
At minimum height, clearance underneath the side rails is reduced. Keep your feet away from the areas
below the side rails and take extra care when using patient hoists or similar equipment.
