Parts List: General Parts List
Stedy parts list
Note: Unless otherwise specified (item number x quantity), component quantity is 1.
ITEM QTY DESCRIPTION
1 2 Sling attachment lug
2 1 Cross bar
3 1 Product label
4 1 Side frame (R.H. side)
5 1 Footboard
6 6 M8x20 SS CSK screws
7 4 M8x50 SS CSK screws
8 1 Kneepad
9 1 Side frame (L.H. side)
10 2 Front castor
11 2 Rear castor (braked)
12 1 Seat half (R.H. side)
13 1 Seat half (L.H. side)
14 4 Bushing (not illustrated)
15 2 End cap
16 1 Label set
17 1 Allen key (hex wrench) 5mm (not illustrated)
18 1
Spanner (wrench)
9
/
16
” (not illustrated)
Stedy Spare Parts Kits
PART NUMBER QTY DESCRIPTION
NTX01400.US 1 Operating and Product Care Instructions
NTS0001.20 1 Side frame (L.H. side) spares kit,
(includes: 1, 6x2, 7x2, 9, 10x2, 11x2, 14x2, 16, 17, 18)
NTS0002.20 1 Side frame (R.H. side) spares kit
(includes: 1, 4, 6x2, 7x2, 10x2, 11x2, 14x2, 17, 18)
NTS0003.20 1 Kneepad spares kit
(includes: 1x2, 7x4, 8, 17, 18)
NTS0004 1 Footboard spares kit
(includes: 5, 6x4, 17)
NTS0005 1 Seat half (L.H. side) spares kit
(includes: 6, 13, 15, 17)
NTS0006 1 Seat half (R.H. side) spares kit
(includes: 6, 12, 15, 17)
NTS0009.20 1 Fixings kit
(includes: 1x2, 6x6, 7x4, 17, 18)
NTS0010.20 1 Crossbar spares kit (includes: 1x2, 2, 3, 18)
NTS0012.20 1 Casters spare kit
(includes: 10x2, 11x2)
Screws must be installed with Loctite glue #262 included with kits.
