9. Press UP button during the CLOCK display
state, to change 12-24 hour mode.
To reset incorrect time, repeat above steps.
After finishing set up, plug the meter into a
regular power outlet. Plug in an appliance that
you want to use and turn the mains power on.
The meter will now measure the consumption of
the appliance.
STAND BY MODE
Display of LCD will disappear without any
operation once AC power is off for 1 minute.
Press any key to bring up the display.
SPECIFICATIONS
Power supply 250V AC 50Hz
Max. load 10A, 2500W
Measure voltage range 210-301V AC
Measure voltage accuracy +/-3%
Measure current range 0.02-10A
Measure current accuracy +/-3% or +/-0.03
Measure power range 0-3010W
Measure power accuracy +/-4% or +/-10W
Accumulative electric quantity range 0-9999.9kWh
Measure frequency range 45-65Hz
Clock accuracy +/-1 minute per month
Power cost <2W
Operating temperature -10°C to +40°C
Battery 2 x 1.5V LR44/AG13
Battery Life About 3 months without AC power
