2 ENG USER MANUAL ELF C2
REV_00-0003
Specifications
Headlamp: simple one-hand operation, reliable headmount. Solid body
without long wires, weak rubber connectors and unnecessary boxes.
The flashlight is easily installed, removed and 180° rotatable in the
mount. Quick-release rubber ring provides additional fixation
Every Day Carry light: compact design, convenient side button, spe-
cial matt anti-abrasive finish without rough knurling, strong built-in tail
magnet and robust removable steel clip
Bicycle light: body made from durable and lightweight aircraft-grade
aluminium, improved shock resistance, new springs for better battery
and driver protection. Constant light without flickering, optional
quick-release mount
Lamp mode: works without batteries directly from a Powerbank or
any USB adapter
• Multicolor temperature, battery level, charging process and state
indication with the ability to turn o the latter
• Convenient wide beam of fully upgraded optical system, TIR-lense
is protected from scratches by tempered glass with anti-reflective
coating
• Innovative technology allows using any 18650 Li-Ion batteries even
without additional protection circuit board
• Active real-time temperature control to prevent overheating
above +58 °C
• Total protection from water, dirt and dust in accordance with IP68
standard — flashlight continues to work even at 10 meters depth.
Withstands fallings from up to 10 meters
• Robust and water resistant Micro USB socket even without rubber
cover
Set description
Flashlight, 18650 Li-Ion battery 3200 mAh, Micro USB cable, clip,
headmount, 2 spare O-rings, user manual.
The producer reserves the right to change the package at his own
discretion without modifying this manual. Specifications are sub-
ject to change without notice.
ENG USER MANUAL
Thank you for choosing the products of Armytek.
Please read this manual carefully before using the flashlight.
Model Elf C2 (White)
LED/Optics Samsung LH351D/TIR
Brightness stabilization type DIGITAL (CPU brightness control)
Light output 1100 lm
Peak beam intensity 2770 cd
Hotspot : Spill 70°:120°
Beam distance 105 m
Modes, light output and runtimes (measured with 18650 Li-Ion
3200 mAh battery until the light output drops to 10% of the
initial value)
Turbo 1100 lm/2 h 32 min (650 lm after 4 min)
Main3 500 lm/3 h 45 min
Main2 220 lm/10 h
Main1 40 lm/51 h
Firefly2 2 lm/26 d
Firefly1 0.11 lm/200 d
Power source 1x18650 Li-Ion
Length/Body diameter/Head diameter 111.3 mm/20.4 mm/33 mm
Weight without/with battery 65 g/115 g
Submersion and Impact resistance IP68, 10 m for 2 h. Height up to 10 m
X Light output for flashlights with Warm light is about 7% less, beam distance is about 3% less.
All the above specifications are test results based on ANSI/NEMA FL1-2009 Standard. The tests are performed using the battery included in the set.
The data may vary due to environment, heat dissipation and other factors.
