2 ENG USER MANUAL WIZARD C2 PRO MAX LR REV_00-0000
Specifications
1. Headlamp: simple one-hand operation, reliable headmount. Solid
body without long wires, weak rubber connectors and unnecessary
boxes. The flashlight is easily installed, removed and 180° rotatable in
the mount. Quick-release silicone ring provides additional fixation
2. Every Day Carry light: compact design, convenient side button,
special matt anti-abrasive finish without rough knurling. Durable nylon
holster, robust removable steel clip and strong built-in tail magnet
3. Sports flashlight: body made from durable and lightweight
aircraft-grade aluminium, improved shock resistance. New springs for
better battery and driver protection, constant light without flickering.
Multiple variants of installation, optional accessories for mounting on
sporting gear
• Pro Max New generation electronics provides impressive light output
of 4150 lumens. Constant brightness even at low ambient temperatu-
res and not fully charged battery
• Pro Multicolor temperature, battery level and state indication
• Special precisely calculated reflector for powerful wide LED and tem-
pered glass with anti-reflective coating create large central spot and
wide side spill at impressive brightness and throw distance
• Innovative technology allows using any standard 21700 Li-Ion or
18650 Li-Ion battery with 15A discharge current. Full protection
against short circuit even in case of contact between magnetic con-
nector and metal objects
• Active real-time temperature control to prevent overheating above
+58 °C
• Total protection from water, dirt and dust in accordance with IP68
standard — flashlight continues to work even after submersion at
10 meters depth. Withstands fallings from up to 10 meters
• Robust and water resistant magnetic connector
ENG USER MANUAL
Thank you for choosing the products of Armytek.
Please read this manual carefully before using the flashlight.
Model Wizard C2 Pro Max LR (white light) Wizard C2 Pro Max LR (warm light)
Optics Smooth reflector
Brightness stabilization type FULL (constant light)
Light output 4150 lm 3870 lm
Peak beam intensity 8190 cd 8100 cd
Hotspot : Spill 35°:85°
Beam distance 181 m 180 m
Modes, light output and runtimes (measured
with 21700 Li-Ion 5000 mAh battery until the
light output drops to 10% of the initial value)
Turbo2 4150 lm/3 h 15 min (900 lm after 50 sec) 3870 lm/3 h 15 min (840 lm after 50 sec)
Turbo1 1300 lm/3 h 20 min (900 lm after 12 min) 1210 lm/3 h 20 min (840 lm after 12 min)
Main3 450 lm/7 h 420 lm/7 h
Main2 150 lm/21 h 140 lm/21 h
Main1 45 lm/64 h 42 lm/64 h
Firefly2 7 lm/10 d 6.5 lm/10 d
Firefly1 0.6 lm/62 d 0.5 lm/62 d
Strobe3 4150 lm/10 Hz/6 h 50 min (900 lm after 2 min) 3870 lm/10 Hz/6 h 50 min (840 lm after 2 min)
Strobe2 4150 lm/1 Hz/14 h (900 lm after 10 min) 3870 lm/1 Hz/14 h (840 lm after 10 min)
Strobe1 150 lm/1 Hz/90 h 140 lm/1 Hz/90 h
Power source 1x21700 Li-Ion, 1x18650 Li-Ion
Time of charging (21700 Li-Ion 5000 mAh battery) 5 h 20 min
Length/Body diameter/Head diameter 121.5 mm/23.6 mm/34.4 mm
Weight without/with battery 81 g/151 g
Ingress protection, Submersion and Impact resistance IP68. Depth up to 10 m for 5 h. Height up to 10 m
X All the above specifications are test results based on ANSI/PLATO FL 1-2019 Standard. The data may vary due to environment, heat dissipation and other factors.
