2 ENG USER MANUAL WIZARD C2 REV_00-0004
Specifications
1. Headlamp: simple one-hand operation, reliable headmount. Solid
body without long wires, weak rubber connectors and unnecessary
boxes. The flashlight is easily installed, removed and 180° rotatable in
the mount. Quick-release silicone ring provides additional fixation
2. Every Day Carry light: compact design, convenient side button,
special matt anti-abrasive finish without rough knurling. Robust
removable steel clip and strong built-in tail magnet
3. Sports flashlight: body made from durable and lightweight
aircraft-grade aluminium, improved shock resistance, constant light
without flickering. Multiple variants of installation, optional accessories
for mounting on sporting gear
• Possibility to set the timer for automatic switching-o
• Convenient wide beam of fully upgraded optical system, steel bezel
and tempered glass with anti-reflective coating for protection of the
TIR-lens
• Innovative technology allows using any standard 18650 Li-Ion
battery. Full protection against short circuit even in case of contact
between magnetic connector and metal objects
• Active real-time temperature control to prevent overheating above
+58 °C and warning indication of low battery level
• Total protection from water, dirt and dust in accordance with IP68
standard — flashlight continues to work even after submersion at
10 meters depth. Withstands fallings from up to 10 meters
• Robust and water resistant magnetic connector
ENG USER MANUAL
Thank you for choosing the products of Armytek.
Please read this manual carefully before using the flashlight.
Model Wizard C2 (white light) Wizard C2 (warm light)
Optics TIR
Brightness stabilization type DIGITAL (CPU brightness control)
Light output 1200 lm 1120 lm
Peak beam intensity 2890 cd 2800 cd
Hotspot : Spill 70°:120°
Beam distance 108 m 106 m
Modes, light output and runtimes (measured
with 18650 Li-Ion 3200 mAh battery until the
light output drops to 10% of the initial value)
Turbo 1200 lm/2 h 45 min (580 lm after 4 min) 1120 lm/2 h 45 min (540 lm after 4 min)
Main3 390 lm/4 h 45 min 363 lm/4 h 45 min
Main2 180 lm/11 h 167 lm/11 h
Main1 40 lm/51 h 37 lm/51 h
Firefly2 2 lm/26 d 1.9 lm/26 d
Firefly1 0.11 lm/200 d 0.1 lm/200 d
Power source 1x18650 Li-Ion
Time of charging (18650 Li-Ion 3200 mAh battery) 3 h 20 min
Length/Body diameter/Head diameter 112 mm/20.4 mm/33 mm
Weight without/with battery 64 g/114 g
Ingress protection, Submersion and Impact resistance IP68. Depth up to 10 m for 5 h. Height up to 10 m
X All the above specifications are test results based on ANSI/PLATO FL 1-2019 Standard. The data may vary due to environment, heat dissipation and other factors.
