- 38 -
Install the inverter by coupling it to a flat, vertical wall to ensure
proper heat dissipation. The air is extracted by the fan on the
bottom of the inverter leaves from the top at the back of the
inverter, as shown in the image.
Inverters can be set alongside one another, but do not overlap
them to avoid overheating the higher positioned inverter.
If overlapping the inverters is necessary, leave a space equal
at least to the “Minimum ventilation space”.
In order to ensure a high level of productivity, it is preferable to
adopt staggered installation, leaving a space equal to at least
the “Minimum distance” between one row of inverters and the
next.
It is advisable to install the inverter in an easily accessible position.
