- 39 -
CONTENTS OF THE ACCESSORIES BOX
Ferrules for AC connection
CONN. MC4 M 2.5-6mm2 MOVABLE
DC connectors are provided in a number equal to the
“Number of pairs of DC connectors”
CONN. MC4 F 2.5-6mm2 MOVABLE
DC connectors are provided in a number equal to the
“Number of pairs of DC connectors”
For connecting additional ground (only required in certain
countries)
Ø9 mm hooks and plugs for wall mounting
MECHANICAL INSTALLATION
Given its low weight, the inverter is installed without the use of
a wall bracket.
In order to install the plugs included in the pack, follow the
drilling template on the right (dimensions in millimetres).
