arpha D01 - Prepare for Installation; Installation Overview

Prepare for Installation
Note: Please prepare a Phillips screwdriver, a drill and 4 AA
batteries before installation.
Check your door dimensions to make sure that they fit the
following measurements:
•The door hole diameter is 54mm (2⅛")
•Backset is 60mm (2⅜") or 70mm (2¾")
•The door thickness is 35mm (1⅜") to 55mm (2 ⅛")
2⅛"
54mm
1½"
38m m
or
Backset
60mm(2⅜")or
70mm(2¾")
Door
thickness
35mm(1⅜")-
55mm(2⅛")
Installation Overview
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1616
17
18
19
20
21
① Front Panel
② Connection Column (M4*1.5inch) * 1
③ Front Panel Block ④ Deadbolt ⑤ Pick Jack
⑥ Connection Wire ⑦ Iron Plate
⑧ Connection Column Screw (M4*1.5inch) * 1
⑨ Back Panel ⑩ Back Panel Screw (M4*0.4inch) *1
⑪ Battery Cover ⑫ Reset Button ⑬ Back Cover
02 03
