Array electronic 3721A User Manual

71
Environmental Conditions
Temperature
Relative Humidity
0~50ºC
≤85%
0~50ºC
≤85%
Remote Interface
*6
RS232, GPIB, USB RS232, GPIB, USB
Programming Language
SCPI SCPI
AC Input
Voltage
Frequency
AC110V or AC220V±15%
48 to 63Hz
AC110V or AC220V±15%
48 to 63Hz
Net Weight
5.8kg 5.8kg
Model
3722A 3723A
Input Ratings
Current
Voltage
Power
*1
0~20A
0~200V
200W at 40ºC
0~30A
0~200V
350W at 40ºC
Input Characteristics
Input Characteristics
Minimum Operation Voltage
@ Full Scale Current
1.2V 1.2V
Constant Current Mode
Low Range
Resolution
Accuracy
0~2A
0.1mA
0.1%+5mA
0~3A
0.1mA
0.1%+5mA
High Range
Resolution
Accuracy
0~20A
1mA
0.1%+10mA
0~30A
1mA
0.1%+10mA
Constant Voltage Mode
Range
Resolution
Accuracy
0~200V
2mV
0.1%+25mV
0~200V
2mV
0.1%+25mV
Constant Resistance Mode
