ARRI SkyPanel S30 - RGBW (8-bit) Mode; HSI (8-bit) Mode; CCT & RGBW (16-bit) Mode

Protocol
56
Mode 4: RGBW, 8 bit Resolution per Function Mode 5: HSI, 8 bit Resolution per Function
Mode 6: CCT & RGBW, 16 bit Resolution per Function
Channel Value Percent Function
1
0-255 0-100
Master Intensity
0 %  100% (open)
2
0-255 0-100
Intensity red
0%  100%
3
0-255 0-100
Intensity green
0%  100%
4
0-255 0-100
Intensity blue
0%  100%
5
0-255 0-100
Intensity white
0%  100%
6
Reverts to
fixture set-
ting when
signal lost.
0-9
10-60
61-120
121-180
181-250
251-255
0-4
5-23
24-47
48-70
71-98
99-100
Fan Control
No function
Low
Variable
High
Fan max. speed
Fan off
7-9 Reserved (only V4.x)
Channel Value Percent Function
1
0-255 0-100
Master Intensity
0 %  100% (open)
2
0-255 0-100
Hue
0°  360°
3
0-255 0-100
Saturation
0  full saturated
4
Reverts to
fixture set-
ting when
signal lost.
0-9
10-60
61-120
121-180
181-250
251-255
0-4
5-23
24-47
48-70
71-98
99-100
Fan Control
No function
Low
Variable
High
Fan max. speed
Fan off
5-7 Reserved (only V4.x)
Channel Value Percent Function
1HI
0-65.535 0-100
Master Intensity
0 %  100% (open)
2LO
3HI
0 - 65.535 0 - 100
Color Temperature CCT
2.800 K  10.000 K
4LO
