ARRI SkyPanel S30 - Gel 1 and Gel 2 Settings; Gel Transition Types; Gel 2 Selection and Matching

Protocol
63
6
0-255 0-100
Gel 1
See tables below
7
0 - 255 0 - 100
Xfade to Gel
Gel 1  Gel 2
8 0-128
129-255
0-50
51-100
Gel 2,CCT Selection
3.200 K
5.600 K
9
0-128
129-170
171 - 255
0-50
51-67
68 - 100
Gel 2, Color Matching
Best Color
Color quality optimized
Brightest
Color brightness opt.
No Color Gel
10
0-128
129-255
0-50
51-100
Gel 2, Brand
Category on ch. 11
Gel on ch. 12
Rosco
LEE Filters
11
0-50
51-101
102-152
153-203
204- 255
0-20
21-39
40-60
61-80
81-100
Gel 1, category
Manufacturer on ch. 10
Category 1:
Rosco: Color Correction
LEE: Color Correction
Category 2:
Rosco: CalColor
LEE: Color Filters
Category 3:
Rosco: Storaro Selection
LEE: 600 Series
Category 4:
Rosco: Cinelux
LEE: Cosmetic Filters
Category 5:
LEE: 700 Series
Channel Value Percent Function
12
0-255 0-100
Gel 2
See tables below
13
0 – 51
52 – 102
103 – 153
154 – 204
205 - 255
0 – 20
21 – 40
41 – 60
61 – 79
80 - 100
Gel Transition Type
Direct
Through White Point
Through Black Point
Over White Point
Under White point
14
Reverts to
fixture set-
ting when
signal lost.
0-9
10-60
61-120
121-180
181-250
251-255
0-4
5-23
24-47
48-70
71-98
99-100
Fan Control
No function
Low
Variable
High
Fan max. speed
Fan off
15-17 Reserved (only V4.x)
Channel Value Percent Function
