ARRI SkyPanel S30 - XY Coordinates (8-bit) Mode; XY Coordinates (16-bit) Mode

Protocol
71
Mode 18: xy Coordinates, 8 bit Resolution per Function Mode 19: xy Coordinates, 16 bit Resolution per Function
Channel Value Percent Function
1
0-255 0-100
Master Intensity
0 %  100% (open)
2
0-255 0-100
X1 Coordinate
0.0  0.8
3
0-255 0-100
Y1 Coordinate
0.0  0.8
4
0-255 0-100
Xfade
X1, Y1  X2, Y2
5
0-255 0-100
X2 Coordinate
0.0  0.8
6
0-255 0-100
Y2 Coordinate
0.0  0.8
7
0 – 51
52 – 102
103 – 153
154 – 204
205 - 255
0 – 20
21 – 40
41 – 60
61 – 79
80 - 100
Gel Transition Type
Direct
Through White Point
Through Black Point
Over White Point
Under White point
8
Reverts to
fixture set-
ting when
signal lost.
0-9
10-60
61-120
121-180
181-250
251-255
0-4
5-23
24-47
48-70
71-98
99-100
Fan Control
No function
Low
Variable
High
Fan max. speed
Fan off
9-11 Reserved (only V4.x)
Channel Value Percent Function
1HI
0-65.535 0-100
Master Intensity
0 %  100% (open)
2LO
3HI
0-65.535 0-100
X1 Coordinate
0.0  0.8
4LO
5HI
0-65.535 0-100
Y1 Coordinate
0.0  0.8
6LO
7HI
0-65.535 0-100
Xfade
X1, Y1  X2, Y2
8LO
9HI
0-65.535 0-100
X2 Coordinate
0.0  0.8
10 LO
11 HI
0-65.535 0-100
Y2 Coordinate
0.0  0.8
12 LO
13
0 – 51
52 – 102
103 – 153
154 – 204
205 - 255
0 – 20
21 – 40
41 – 60
61 – 79
80 - 100
Gel Transition Type
Direct
Through White Point
Through Black Point
Over White Point
Under White point
14
Reverts to
fixture set-
ting when
signal lost.
0-9
10-60
61-120
121-180
181-250
251-255
0-4
5-23
24-47
48-70
71-98
99-100
Fan Control
No function
Low
Variable
High
Fan max. speed
Fan off
15 - 17 Reserved (only V4.x)
