Arrow ET2025 - DEFINITION OF SYMBOLS USED ON TOOL; FUNCTIONAL DESCRIPTION; Tool Components Overview

4
BACK TO
INDEX
V …………………………… Volts
A …………………………… Amperes
Hz……………………………. Hertz
……………………………. Alternating Current
……………………………. Alert
……………………………. Wear Eye Protection
……………………………. Wear Ear Protection
……………………………. Double Insulation
DEFINITION OF SYMBOLS USED ON TOOL
FUNCTIONAL DESCRIPTION
1
7
8
6
5
4
3
Depth of Drive Dial
Guide Light
Contact Safety
Wire Attachment
Staple Pusher Assembly
On/Off Switch
Power Cord
Trigger
2
1
2
3
4
5
6
7
8
~
ET2025
™
for 120V
ET2025
™
for 220-240V
& 220-240V(UK)
LISTED
E322184
