Arrow Revolution - Easy Mode Programming Instructions; Feature Programming Through Menu Mode; Open Door With PIN Code

2
P/N LT-503200 Rev A
CAUTION: Changes or modifications to this unit will void the the warranty.
IMPORTANT: The accuracy of the door preparation is critical for the proper functioning and
security of this product. Misalignment can cause performance degradation and a lessening
of security.
Finish Care: This lockset is designed to provide the highest standard of product quality and
performance. Care should be taken to ensure a long-lasting finish. When cleaning is required
use a soft, damp cloth. Using lacquer thinner, caustic soaps, abrasive cleaners or polishes
could damage the coating and result in tarnishing.
Warnings .........................................................................................................................2
Introduction .....................................................................................................................2
Installation
Components and Tools .............................................................................................3
Prepare Lock for Installation .....................................................................................4
Install Lock ............................................................................................................ 5-6
Programming
Programming Features-Menu Keys-Definitions ................................................... 7-8
Operation ............................................................................................................ 9-11
Miscellaneous Information
Return Lock to Programming Defaults ...................................................................12
Hardware Troubleshooting ......................................................................................12
Programming Troubleshooting ...............................................................................13
Replace/Install Cylinder ..........................................................................................14
Sample Pin Code Management Sheet ...................................................................15
TABLE OF CONTENTS
WARNINGS
INTRODUCTION
The Arrow® Revolution™ Stand-alone Touchscreen Deadbolt Lock combines a robust lockset
with a contemporary electronic aesthetic.
Users benefit from an interactive touchscreen that makes day-to-day access effortless, as well as
offering voice-guided programming for simple updates to user information in the event of staffing
changes or security breaches. Arrow Revolution is engineered for quick and easy installation and
fits in place of a standard deadbolt lock door prep (ANSI/BHMA A156.115).
