HARDWARE LIST...
Hardware Views by Key No.
06FX
2
1
3
Key Part Part Qty.
No. No. Description List
1 65923 Bolt (#8-32 x 3/8) (10 mm) 63
2 65103 Hex Nut (#8-32) 63
3 65004 Screw (#8AB x 5/16) (8 mm) 266
4 66646 Washer Sheet 3
5 66715 Door Handle 1
6 66718 Hinge 4
7 66720 Padlock Eyelet 2
8 60H Corner Cap 4
9 66870 Plastic Trim 2
9
6
The fasteners used in each step are shown
actual size at the top of each page. If you
are unsure which fastener to use, hold it up
to the picture and use the one that matches.
8
4
5
7
10
10 66871 Plastic Corner Trim 3
11 66808 Latch Spring 1
12 66721 U-Nut (Door Clip) 8
11
12
13 66866 Door Closure Clip 4
14 11137 Mounting Plate 2
13
14
