1 Lift and fasten a right and left
gable, under angle at corner, to the
rear wall angle with screws.
2 Join the left and right gables
together with a gable brace using a
bolt in the bottom hole
only
.
3 Repeat Steps 1 & 2 for the door
track on the front of building, except
for the track supports, fasten as
shown.
●●
●●
● Left Gable Assemblies (2)
●●
●●
● Right Gable Assemblies (2)
●●
●●
● 6635 Gable Brace (2)
● Parts Needed For ●
Gables/Braces
Step 14
SX27
27
STEP
2
STEP
3
STEP
1
6635 Gable Brace
6000
6001
Track Supports 6228
Gable
To Next Page
