Arrow WR108 - Stud Installation

23
EN,FR,SP-23KN
5: STUDS
9344
6
Front
Avant
Frente
65004
10
MONTANTS
PERNOS
9365
9344
9344
9344
9344
9344
9344
9365
22 7/8”
(58,1 cm)
68 7/16” (173,8 cm)
29 15/16” (76,0 cm)
89 11/16” (227,8 cm)
9365
2
Washer
Rondelle
Arandela
65004
66646
9365
9344
65004
65004 66646
2
9344
65004
