Arrowhead Elite S - Smoke Detector Zone Wiring (Type 3); Type 3: Single Smoke Detector Wiring; Type 3: Multiple Smoke Detector Wiring

1
2
4
3
Gnd 12V 1 C 2 3 C 4
Outputs
Gnd 12V 1 2 3 4
2k2
Smoke 1 = Zone 4
*The End of Line Resistor must be fitted in the last detector.
*If Multiple detectors are sharing the same zone, they must be wired in a daisy-chain format.
Smoke Detector Zone Wiring (Type3)
Gnd 12V 1 C 2 3 C 4
Outputs
Gnd 12V 1 2 3 4
2k2
1
2
4
3
1
2
4
3
1
2
4
3
Zone 4 = Smoke 1,2 & 3
To smoke 2 &3
To smoke 3
EOL
EOL
EOL
