Table 4: ClearPass C3000 Appliance Specifications
ClearPass C3000 Appliance Specifications
Hardware Model HPE DL360 Gen 9
CPUs (2) Xeon 2.4GHz E5-2620_V3 with Six Cores (12 Threads)
Memory 64 GB Memory
Hard drive storage (6) 300GB Serial-Attach SCSI (SAS) (10K RPM) 60GB Hot-
Plug hard drives (RAID-10 controller)
Out-of-Band Management HPE Integrated Lights-Out (iLO): Advanced
Serial Port Yes: DB-9
Performance &Scale Please refer to the ClearPass Scaling & Ordering Guide
Form Factor
Rack mount
l 1U SFF Easy Install Rail
l 1U Cable Management Arm
Dimensions (WxHxD 17.1” x 1.7” x 27.5”
Weight (max configuration) Up to 33.3 lbs
Power Specifications
Power supply HPE 500W Flex Slot Platinum Hot Plug Power Supply
Power Redundancy Optional
AC input voltage 100/240 VAC auto-selecting
AC input frequency 50/60 Hz auto-selecting
Environmental Specifications
Operating temperature 10º C to 35º C (50º F to 95º F)
13 ClearPass 6.7 Getting Started Guide
