Page #7 background imageLoading...
Page #7 background image
7
SFP Module Specifications
EC-SFP-1000BT
Parameter Typical
LineFrequency 125MHz
TxOutputImpedance 100Ohm
RxInputImpedance 100Ohm
TxInputImpedance 50Ohm
RxInputImpedance 50Ohm
SFP+ Module Specifications
EC-SFP-SR
Parameter Minimum Maximum
OpticalOutputPower(1G) –9.5dBm –1dBm
OpticalReceiveSensitivity(1G) –17dBm
MaximumInputPower(1G) +0.5dBm
OpticalOutputPower(10G) –5dBm –1dBm
OpticalReceiveSensitivity(10G)  –11.1dBm
MaximumInputPower(10G) +0.5dBm
EC-SFP-LR
Parameter Minimum Maximum
OpticalOutputPower(1G) –11dBm –3dBm
OpticalReceiveSensitivity(1G)  –19dBm
MaximumInputPower(1G)  –3dBm
OpticalOutputPower(10G) –8.2dBm +0.5dBm
OpticalReceiveSensitivity(10G)  –12.6dBm
MaximumInputPower(10G) –14.2dBm +0.5dBm
EC-SFP-10G-LR
Parameter Minimum Maximum
OpticalOutputPower(10G) –8.2dBm +0.5dBm
OpticalReceiveSensitivity(10G)  –12.6dBm
MaximumInputPower(10G) –14.2dBm +0.5dBm
