Ascaso BARISTA T ZERO - Machine Components and Functionality

COMPONENTSAND FUNCTION BARISTATPLUS/ZERO
COLDWATERDISTRIBUTOR
Thispart,placedintherightside,underthe
boilerisaspecialfittingthatdistributesthecold
wátertothesteamboiler,thecoffeegroups,
theheat‐exchangerandthemixerofthehot
wáterdispenser.
Intheconnectionoftheheat‐exchangerthereis
anon‐returnvalve.
INLETWATERTOFILLBOILER
Thisisthesolenoidconnectedwiththe
boilerlevelprobe.Whenthelevelis
low,thesolenoidopenandrefillthe
boiler.
Inonesidehaveconnectedanon‐
returnvalve.
