ASHDOWN ENGINEERING - STUDIO RANGE
Studio 12
Output Power 100watts rms into 8 ohms
Speaker Unit 1 x 12” Ashdown Driver
Input Impedance 1 Meg ohm
Input Signal Range 100Mv to 10v
E.Q. Bass, Hi-Mid, Middle, Lo-Mid, Treble
Dimensions (mm) H:472* W:414 D:357
Weight 10.3Kgs 22.7Lbs
Studio 15
Output Power 300watts rms into 8 ohms
Speaker Unit 1 x 15” Ashdown Driver & Tweeter
Input Impedance 1 Meg ohm
Input Signal Range 100Mv to 10v
E.Q. Bass, Hi-Mid, Middle, Lo-Mid, Treble
Dimensions (mm) H:526* W:428 D:378
Weight 11.2Kgs 24.6Lbs
Studio 210
Output Power 300watts rms into 8 ohms
Speaker Unit 2 x 10” Ashdown NEO Driver & Tweeter
Input Impedance 1 Meg ohm
Input Signal Range 100Mv to 10v
E.Q. Bass, Hi-Mid, Middle, Lo-Mid, Treble
Dimensions (mm) H:526* W:428 D:378
Weight 11.2Kgs 24.6Lbs
* + 20mm for feet
SPECIFICATIONS
