Ashdown STUDIO Series - Studio Range Specifications

ASHDOWN ENGINEERING - STUDIO RANGE
SPECIFICATION:
Studio Jnr
Output Power 15watts rms into 8 ohms
Speaker Unit 1 x 6” Ashdown Driver
Input Impedance 1 Meg ohm
Input Signal Range 100Mv to 10v
E.Q. Passive Bass, Middle, Treble.
Weight 6Kgs 13.1Lbs
Studio 8
Output Power 30watts rms into 8 ohms
Speaker Unit 1 x 8” Ashdown Driver
Input Impedance 1 Meg ohm
Input Signal Range 100Mv to 10v
E.Q. Passive Bass, Middle, Treble.
Dimensions (mm) H:336* W:360 D:227
Weight 6.1Kgs 13.4Lbs
Studio 10
Output Power 60watts rms into 8 ohms
Speaker Unit 1 x 10” Ashdown Driver
Input Impedance 1 Meg ohm
Input Signal Range 100Mv to 10v
E.Q. Passive Bass, Middle, Treble.
Dimensions (mm) H:366* W:360 D:302
Weight 7Kgs 15.4Lbs
Studio 12
Output Power 100watts rms into 8 ohms
Speaker Unit 1 x 12” Ashdown Driver
Input Impedance 1 Meg ohm
Input Signal Range 100Mv to 10v
E.Q. Bass, Hi-Mid, Middle, Lo-Mid, Treble
Dimensions (mm) H:472* W:414 D:357
Weight 10.3Kgs 22.7Lbs
ASHDOWN ENGINEERING - STUDIO RANGE
Studio 15
Output Power 300watts rms into 8 ohms
Speaker Unit 1 x 15” Ashdown Driver & Tweeter
Input Impedance 1 Meg ohm
Input Signal Range 100Mv to 10v
E.Q. Bass, Hi-Mid, Middle, Lo-Mid, Treble
Dimensions (mm) H:526* W:428 D:378
Weight 11.2Kgs 24.6Lbs
Studio 210
Output Power 300watts rms into 8 ohms
Speaker Unit 2 x 10” Ashdown NEO Driver & Tweeter
Input Impedance 1 Meg ohm
Input Signal Range 100Mv to 10v
E.Q. Bass, Hi-Mid, Middle, Lo-Mid, Treble
Dimensions (mm) H:526* W:428 D:378
Weight 11.2Kgs 24.6Lbs
Studio Minirig
Output Power 180 watts into 4 ohms min load
Speaker Unit 2 x 10” Ashdown NEO Driver & Tweeter
Input Impedance 1 Meg ohm
Input Signal Range 100Mv to 10v
E.Q. Bass, Hi-Mid, Middle, Lo-Mid, Treble
Dimensions (mm) HEAD: 170 x 400 x 300 CABINET: 690 x 400 x 350
Weight (kg) HEAD: 7.74 CABINET: 18
* + 20mm for feet
