INTRODUCTION
The instructions pertaining to the installation of your wood stove comply with UL 1482-2022 and CAN/ULC
S627:2023 standards. This manual describes the installation and operation of the Ashley, AW2020E wood
heater. This heater meets the 2020 U.S. Environmental Protection Agency’s cordwood emission limits for
ɩȌȌƮǘƵƊɈƵȲȺȺȌǶƮƊǏɈƵȲwƊɯׁׅةׂ׀ׂ׀خÇȁƮƵȲȺȯƵƧǞ˛ƧɈƵȺɈƧȌȁƮǞɈǞȌȁȺɈǘǞȺǘƵƊɈƵȲǘƊȺƦƵƵȁȺǘȌɩȁɈȌƮƵǶǞɨƵȲ
ǘƵƊɈƊɈȲƊɈƵȺȲƊȁǐǞȁǐǏȲȌǿׁׅةׂ׆ׁ ɈȌ׆׃ةׁ׉׆ ɈɐشǘȲɩǞɈǘׁ ǐشǘȲƊȁƮׇ׀ڭƵǏ˛ƧǞƵȁƧɯخyȌɈƵبÀǘƵ ÀÇȲƊɈǞȁǐȺ
ǿƵȁɈǞȌȁƵƮƊƦȌɨƵƊȲƵƦƊȺƵƮȌȁɈǘƵ0§ɈƵȺɈȯȲȌɈȌƧȌǶɐȁƮƵȲȺȯƵƧǞ˛ƧɈƵȺɈƧȌȁƮǞɈǞȌȁȺخɐȲƊƮɨƵȲɈǞȺƵƮ ÀÇٚȺ
ƊȲƵƦƊȺƵƮȌȁɈǘƵ˛ȲȺɈǘȌɐȲȌǏȌȯƵȲƊɈǞȌȁƊɈǘǞǐǘƦɐȲȁȲƊɈƵƦɐȲȁǞȁǐƧȌȲƮɩȌȌƮخ
Combustible: Wood
Colors: Black
Flue Pipe Diameter: 6” (152.5 mm)
Flue Pipe Type: (Standard Single
Wall or Double Wall):
Black or Blued Steel 2100°F (650°C)
Minimum Chimney Height: 12’ (3.7 m)
Maximum Log Length: 21” (534 mm)
Dimensions
w(0m DEPTH WIDTH HEIGHT
ɨƵȲƊǶǶب(ƵȯɈǘɮàǞƮɈǘɮRƵǞǐǘɈب
AW2020E (Leg) 20.9” (531 mm) 29.4” (747 mm) 31.3” (796 mm)
AW2020E (Pedestal) 21.1”(536 mm) 27”(686 mm) 31.4”(798 mm)
Combustion Chamber: Width x
Depth:
22-3/4” X 11.78” (578 mm X 300 mm)
Volume: Cubic Feet: 1.6 cubic feet
(ȌȌȲȯƵȁǞȁǐبàǞƮɈǘɮRƵǞǐǘɈب 18” X 9.75” (458 mm X 248 mm)
Pyroceramic Glass Door:
(Viewing) Width x Height:
16” X 10.3” (407 mm X 262 mm)
ȯɈǞȌȁƊǶƧƧƵȺȺȌȲǞƵȺ
ɐɈȺǞƮƵǞȲXȁɈƊDzƵjǞɈ 4FAK
CAUTIONS:
• HOT WHILE IN OPERATION. KEEP CHILDREN, CLOTHING AND FURNITURE AWAY. CONTACT MAY
CAUSE SKIN BURNS.
• DO NOT USE CHEMICALS OR FLUIDS TO IGNITE THE FIRE.
• DO NOT LEAVE THE STOVE UNATTENDED WHEN THE DOOR IS SLIGHTLY OPENED.
• DO NOT BURN GARBAGE, FLAMMABLE FLUID SUCH AS GASOLINE, NAPHTHA OR MOTOR OIL.
• DO NOT CONNECT TO ANY AIR DISTRIBUTION DUCT OR SYSTEM.
• ALWAYS CLOSE THE DOOR AFTER THE IGNITION.
For Customer Service, please call:
1-800-750-2723 Ext 5050 or;
Text to 423-301-5624 or;
Email us at:
customerservice@usstove.com
Note: Register your product online at
www.usstove.com or download the
free app today. This app is available only
on the App Store for iPhone and iPad.
Search US Stove. Save your receipt with
your records for any claims.
