Ashly 2.24GS - 13 Dimensions; 14 Specifications

19
Operating Manual - PROTEA SYSTEM II Digital Audio Products
13. DIMENSIONS
14. SPECIFICATIONS
Input Active Balanced, 18KΩ
Max. Input Level +20dBu
Output Pseudo-Balanced, 100Ω
Max. Output Level +20dBu
Frequency Response 20Hz to 20KHz, ±0.25dB
THD <0.01% @ 1KHz, +20dBu
Dynamic Range >110dB 20Hz - 20KHz unweighted
Signal Present & Clip -15dBu, +20dBu
Audio Sampling Rate 48KHz
Propagation Delay 1.46mS
Remote Distance >1000 ft
AC Requirements 90-125VAC, 50/60Hz,
180VAC - 250VAC 50/60Hz switchable
Environmental 40°F - 120°F (4°C-49°C)
Non-condensing
Model Weight Power
4.24G 14 Lbs 30W
4.24RD 5 Lbs NA
4.24GS/PS 13 Lbs 27W
2.24GS/PS 9 Lbs 20W
6.50
4.24RD Remote
5.36
16.94
1.65
4.24G Main
3.25
3.50
0.00
0.25
2 Channel Slaves
6.50
0
.
0
0
0
.
2
5
1
8
.
7
5
1
9
.
0
0
0.00
0.25
1.50
1.75
8.50
4 Channel Slaves
3.25
3.50
0.00
0.25
