PAGE 3
PAneL DesCRIPtIons
1. Hi Gain Input: �” jack for passive bass input.
2. Low Gain Input: �” jack for active bass input.
3. Volume: This controls the overall volume of the amplifier.
4. Bass: Controls the amount of low frequency in the output sound of the amplifier.
5. Middle: Controls the amount of middle frequency in the output sound of the amplifier.
6. Treble: Controls the amount of high frequency in the output sound of the amplifier.
7. Presence: Controls the presence (depth) of the output sound of the amplifier.
8. MP3 Input: This input is a general AUX input for MP3 players. Please refer to the ‘using
the MP3 input’ section onthe next page before using this feature of the amplifier.
9. Headphones: Use this input for headphone operation.
10. Power: Turns the amp on and off.
