ASI DataMyte 600 - Page 49

Rev 3 Page 49
3. Select View Option 1 and press Enter. Select XBar & R chart. This will bring up a
control chart when the View button is pressed.
4. Select View 2 Option and select the Histogram.
Note: To bring up the view 2 option, press SHIFT and then VIEW buttons.
5. Select Save Torque Option and select the Exceptions setting. This will save torque
curves that are out of spec or when a torque reading fails.
6.
7. Select Menu to return to the main menu. Connect the gage to the 600 that you
will use for data collection.
