1. Connect the serial cable. The TranSend II RCSL application uses a direct-connect cable to
establish a communications link with an ASI DataMyte data collection device.
Attach one end of the 91714 cable to the designated serial port on your PC and the other end
to the COM Port (designated by the ļļ symbol) on the data collector.
The Serial Baud Rate of the data collector must match that of the PC running the DataMetrics
RCSL application. Once you have properly configured DataMetrics RCSL and your data
collector to communicate together and connected the cable, you are ready to perform a
transfer.
3. On the DataMetrics RCSL main screen, click on SPC Database icon as the Source.
The Show Filtered Setup Groups will appear in the view window as default.
