EN 14
If necessary, adjust the whole filter holder unit and proceed as follows:
• Loosen the four adjustment screws Vr and close the glass panel
again.
• Move the entire filter holder unit until it is properly aligned with the
shelf.
• Keeping the hood casing still, remove the glass panel and lock the
adjustment screws again.
• The hood can now be fastened to the shelf using the four screws
12a (3.5 x 16) provided.
• Replace the metal grease filters.
• Close the sliding glass panel again.
INSTALLATION
12a
12a
