Specifications are subject to change without notice. See installation instructions for additional details.
26
DIMENSIONS
US Metric
Height 67"–69" 1702–1753 mm
Width 23-7/16" 595 mm
Depth 24-7/16" 621 mm
Weight 253–260 lbs 115–118 kg
WARNING! Never stack a washer on top of a dryer!
Any ASKO dryer can be mounted on top of any matching
ASKO washer. Stacking kits are packed inside the dryer. Refer
to the ASKO Dryer Use and Care Guide for stacking instructions.
Every ASKO washer is delivered ready-fitted with a plug and is
intended for connection to an ASKO dryer, which is equipped with
a matching receptacle. When an ASKO washer is connected to the
dryer, use 220 V, 30 Amp single-phase circuit. When the dryer is
on a separate outlet, use 220 V, 15 Amp single-phase circuit. If
the washer is used separately or with another dryer, it must be
on a separate 220 V, 20 Amp single-phase circuit.
When placing a stacked pair next to a wall or cabinet, be sure to
leave 1/2" (12 mm) of space between the washer and the wall or
cabinet.
See page 21 for venting requirements.
See page 29 for stacked cabinet or closet installation
dimensions.
WARNING! To reduce the risk of fire, vented dryers
must be exhausted OUTDOORS or the equivalent.
Never cover the end of the dryer stub or vent hose with
anything to catch lint, except for a UL-approved vent
basket.
W6661 AND T761 VENTED DRYER
ASKO STACKED LAUNDRY PAIRS
