Asko D3230 - Control panel; Dispenser

10
1. Program selector
2. Pots & Pans
3. Heavy wash
4. Normal wash
5. Delicate wash
6. Quick wash
Control panel
7. Rinse & Hold
8. High temperature
9. Delayed start 5 hours
10. Extra dry
11. Start/stop
Dispenser
1 3
4
5
2
1. Compartment for main wash dish-
washer detergent
2. Compartment for pre-wash detergent
3. Inspection window for rinse aid
4. Rinse aid cover
5. Detergent compartment cover
8
9
10
11
STARTSTART
ENDEND
PC-UPGRADEPC-UPGRADE
P C - U P G R A D E
PROGPROG
P R O G
STARTSTART
S T A R T
STOPSTOP
S T O P
1
2
3
4 5
6
7
