44
SERVICE
2
Changing the drum ridge
1. Remove the three screws at the rear edge and
lift off the top cover.
2. Unscrew the 5 screws that secure the drum rid-
ge.
NOTE
Rotate the drum until you can gain access to the
screws.
3. Secure the new drum ridge.
WARNING
The drum ridges must be installed in each direc-
tion, see the illustration.
4. Fit the top cover.
IMPORTANT
Don't forget the 2 star washers for the outermost
screws.
