8
5 PANEL
1. INDICATOR LAMP ON/OFF
2. MAIN POWER SWITCH
3. PROGRAM SELECTOR KNOB
THE PROGRAMS ARE DESCRIBED IN
CHAPTER 7, BEFORE TUMBLE DRYING.
4. DISPLAY
5. START BUTTON WITH LED TO INDICATE
PROGRAM RUNNING
6. SETTING AND OPTION BUTTONS
7. STOP BUTTON WITH LED TO INDICATE
THAT THE PROGRAM IS COMPLETED
1 4
2
3
5
6 OPTION BUTTONS
7
6
2 3
1. TIME ADJUSTMENT BUTTON FOR TIMED
DRY AND AIR FLUFF PROGRAM
2. ANTI-CREASE PROGRAM BUTTON
3. DELAYED START BUTTON
4. LOW TEMPERATURE BUTTON
5. BUZZER BUTTON
6. QUICK COOLING BUTTON
The LEDs indicate that your choice has been
activated.
654
