12
CONNECTING TO WATER SUPPLY
The machine has to be connected to water
supply by an adequately trained person.
Use the water supply hose to connect the appliance.
Water pressure has to be between 0.1 and 1 MPa
(approximately 1–10 kp/cm
2
, 1-10 bar, 10–100 N/
cm
2
).
If the hoses are newly installed, we recommend
rinsing them to remove any impurities. Otherwise,
these impurities could clog the fi lter in the water
connection on the washing machine and thus cut off
the water supply.
The water intake hose has to be fastened fi rmly
enough for the hose to have a good seal.
After connecting the hose, the seal must be checked
for any leaks.
Only use the water supply hose supplied with the
appliance. Do not use any used or other hoses.
If the connection on the supply hose is of
diff erent dimensions than the water tap (e.g. 3/4” →
1/2”), use an adapter.
INSTALLING THE DRAIN HOSE
Upon delivery, the appliance has a drain hose
attached. This drain hose must be connected to
a drain. Drain hose can also be attached to a wall
drain with a trap; such trap should be properly
installed to allow cleaning. The height of the drain
should be 600–900 mm above the fl oor. The lower
position (600 mm) is always recommended. Make
sure the drain hose is not clipped or bent.
600 - 900 mm
600 - 900 mm
600 - 900 mm
B
C
A
Drain hose can also be connected directly to the
washbasin drain via a siphon. In this case, the hose,
too, should be 600–900 mm above the fl oor. Internal
hose diameter should be at least 18 mm.
See fi gure.
At least 18 mm
