31
CLEANING THE DISPENSER TRAY AND DOOR RUBBER GASKET
1
Press the tab to completely remove the dispenser
tray from its housing.
A B
2
Rinse and thoroughly clean the tray. You may also
remove the cap from the plug in the conditioner
compartment (A). Clean any residue from the cap and
tube.
Clean the dispenser tray (B) interior.
Replace the cap on the plug.
3
Use a brush to clean the nozzles on the upper
side of the dispenser tray housing.
After a washing program, nozzles that clean the
interior of the dispenser are automatically switched on
(only with some models).
4
Replace the detergent dispenser into its housing.
Close the dispenser tank!
Do not wash the dispenser tank in the dishwasher!
5
After every wash, wipe the rubber door seal to
extend its useful life.
