Asko W4114C - Page 46

46
PERFORMANCE DATA
Program Maximum load Temp. °C
Eco 40-60
1*)
11 / 5,5* / 2,7** kg
Universal wash
2)
11 / 5,5* kg 60
Mix/Synthetics
2)
3,5 kg 40
1*)
PRODUCT INFORMATION SHEET According to EU-Regulation No. 2019/2014
2)
40 °C program for testing institutes. The 40 °C option has to be set.
* Half load
** Quarter load
ENERGY LABELLING
European test standard
1*)
Washing program 11 kg cotton
Eco 40-60
1*)
Connection Cold water 15 °C
Noise testing method IEC-60704-2-4
TECHNICAL INFORMATION
Height 850 mm
Width 595 mm
Depth 700 mm
Weight 90,5 kg
Drum volume 80 l
Rated power See rating plate
Heater power See rating plate
Water pressure 0,1–1 MPa
1–10 kp/cm
2
10–100 N/cm
2
Material for the drum and dispenser Stainless steel
Housing material Hot-dip galvanized and powder coated sheet metal, or
stainless steel sheet (depending on model)
Water connection 1.5 m pex hose
Drain hose 1.6 m polypropylene hose
