4. Commissioning of the equipment
4.1. Motor connection
The cover is powered by a dc motor. Location of pool blinds currently underway in the engine, which
contains the sensor. The cable from the engine contains 5 wires. The two wires that are stronger (the red and
grey colors) are attached to the connector with the marking ENGINE. The red cable connects to the clip labelled
+, grey to the clip marked -. After the engagement, it is necessary to check whether the cover when closing is
closing, and not vice versa. If the cover, when closing is opening and when the opening closes, it is necessary
to swap the red and grey cable. The remaining 3 cables (smaller) attach sensor embedded in the engine; these
cables are attached to the connector labelled SENSOR. The brown cable connects to clip S+, black on the clip
SQ, and the blue cable to the clip S -. (annex picture 1)
4.2. Connecting external buttons
4.3. Connecting an External Radio Module
4.4. Connection of auxiliary relay
menu technician
4.5. Connecting the Level Sensor
COMST
4.6. Device location
Do not place electronics into the shafts or other space that is difficult to access the signal from the
remote control and never in a humid environment.
