Install Outdoor Unit
Fix the outdoor unit with anchor bolts (M10)
A
H
Body Dimensions
B
F
D C E
A
H
MODE
A B
C
D
E
F
H
845
586
347
372
312
342
700
18-24K
30-42K
940
600
375
400
340
338
885
600mm
600mm
4 pieces for one unit
Bolt
4 pieces for one unit
Bolt
48K
940
600
375
400
340
338
1250
60K
938
605
410
440
417
372
1369
10
